YJTKK6303-6 Three-phase Asynchronous VVVF Motor Drive 1400kW 995rpm

AIMIN ELECTRICS CO., LTD. is one of the leading manufacturers and suppliers of yjtkk6303-6 three-phase asynchronous vvvf motor drive 1400kw 995rpm in China. With abundant experience, we are committed to providing high quality customized products with competitive price. We warmly welcome you to buy bulk premium products made in China here and get quotation from our factory.

Brief Introduction

Manufactured by XI'AN AIMIN MOTOR CO., LTD., the YJTKK series high-voltage variable frequency three-phase asynchronous motor is professionally developed to match modern industrial variable speed control systems, and the vvvf motor drive serves as the core matching configuration to realize flexible speed regulation, energy-saving operation and stable torque output of this series of motors. Taking the YJTKK6303-6 model on the nameplate as a typical representative, this motor has a rated power of 1400kW, rated voltage of 10000V, rated speed of 995r/min under 50Hz working condition, with an excellent energy efficiency of 94.9% and a power factor of 0.86, which can efficiently convert electric energy into mechanical energy and effectively reduce long-term operating power consumption for enterprises.

This series of motors adopts Class 155 heat-resistant insulation structure and IP54 protection grade, matched with IC666 cooling mode and B3 installation form, and supports S1 continuous working system, which can run stably for a long time under the ambient temperature of -20℃ to 40℃ and the altitude within 1000 meters. In terms of structural configuration, the driving end is equipped with NU238ECM bearing, and the non-driving end adopts 6336/C3 bearing with large load capacity, which can bear heavy radial and axial loads during high-torque operation. The rated output torque of the motor reaches 13370N·m, and the stable operation frequency range covers 5Hz to 70Hz. When cooperating with vvvf motor drive, it can realize stepless speed regulation in a wide range, perfectly adapt to the working conditions of frequent speed change, intermittent start and heavy-load startup in industrial production, avoiding the energy waste caused by traditional throttling speed regulation of fans, water pumps, compressors and other equipment.

All products of this series are strictly produced and inspected in accordance with the JB/T12729 national industry standard, with complete CE certification, meeting the access requirements of domestic and overseas industrial markets. The stator adopts Y-type wiring mode, the rated working current is 98.8A, and the internal winding has excellent anti-aging and voltage resistance performance, which can effectively resist the harmonic impact generated during the operation of frequency conversion equipment and extend the service life of the motor. The whole machine weighs 9440kg, with solid cast iron structure, strong vibration resistance and stable operation, which can adapt to harsh industrial environments such as chemical industry, metallurgy, mining, power plant and water conservancy.

In practical industrial application scenarios, many high-energy-consuming production links need to adjust equipment operating speed according to process demand, and the perfect combination of YJTKK series high-voltage variable frequency motor and vvvf motor drive not only ensures the safety and reliability of equipment operation, but also brings remarkable energy-saving benefits to users. Compared with ordinary fixed-speed high-voltage motors, this series of variable frequency motors can reduce the comprehensive power consumption of the system by 20% to 40% in most fan and pump working conditions. At the same time, the soft start function brought by frequency conversion drive can greatly reduce the impact current at startup, protect the power grid and related supporting electrical equipment, reduce equipment maintenance frequency and after-sales maintenance cost, and become the preferred power supporting equipment for energy-saving transformation and new industrial projects at home and abroad.

Main Technical Parameters

Production Details

Frame

• Box structure frame, easy for maintaining and installation

• Flexible dimensions

• Customizable outlook

---

Stator

• 99.9% pure copper winding ensures the output power and efficiency

• Excellent insulation system with 5 more processing flows

• All the windings are fitted in by handwork to ensure all slots are full and avoid any possible winding flaw.

---

Rotor

• Aluminum casting rotor with high quality silicon steel rotor core to assure induction efficiency

• Copper bar rotor is available for YKK motor

• Pprecisely machined shafts with good capacity of  toughness

---

Testing

• All motors must pass the testing before painting and packaging

• We regularly test existing and new products to ensure quality.

---

Package and delivery

• All motors will be packaged well before delivery

• Plastic cover inside, vacuum tin foil outer and then solid wood box

---



Applications

YJTKK Motor is the widely used in many general industries, such as blowers, pumps, crushers, cutting machines, and many other heavy machines. For more application details, contact us.

Cement

Power Station

Water conservation

Steel
