YBX3-160M -4 High Efficiency 3 Phase Asynchronous Electric Motor 11kw

AIMIN ELECTRICS CO., LTD. is one of the leading manufacturers and suppliers of ybx3-160m -4 high efficiency 3 phase asynchronous electric motor 11kw in China. With abundant experience, we are committed to providing high quality customized products with competitive price. We warmly welcome you to buy bulk premium products made in China here and get quotation from our factory.

Brief Introduction

The YBX3 series is a premium line of high-efficiency, explosion-proof three-phase induction motors engineered to deliver exceptional performance and reliability for hazardous industrial environments. Taking the YBX3-160M-4 electric motor 11kW as a prime example, this motor boasts a rated power of 11kW, a synchronous speed of 1470r/min, and an impressive efficiency rating of 91.4%, which significantly reduces energy waste and lowers operational costs over its lifecycle. With a power factor (cosφ) of 0.85, it optimizes power utilization and minimizes reactive power loss, making it an energy-smart choice for industrial operations.

Designed in strict compliance with Exdb IIBT4 Gb explosion-proof standards and the national standard JB/T 12628-2016, the YBX3 series ensures safe operation in explosive gas atmospheres, preventing potential ignition risks and safeguarding personnel and equipment. It features Class F insulation (thermal class 155) and IP55 ingress protection, enabling it to withstand harsh conditions including ambient temperatures up to 40℃ and altitudes of 1000m. Equipped with dual 6309/C3 bearings (both drive end and non-drive end), this electric motor 11kW offers enhanced mechanical stability and extended service life, reducing maintenance frequency and downtime. The S1 continuous duty rating allows for uninterrupted, long-term operation, perfectly matching the demands of heavy industrial processes.

This series is ideally suited for critical applications across high-risk industries, including petrochemical refining, coal mining, chemical processing, oil and gas extraction, and green energy projects such as green ammonia production. Whether powering pumps, compressors, fans, or conveyors, the YBX3-160M electric motor 11kW combines energy efficiency, robust durability, and explosion-proof safety, making it a trusted and cost-effective solution for businesses seeking reliable performance in the most challenging operational environments.

Main Technical Parameters

Why choose AIMIN Brand YBX3 series of Motor?

The YBX3 series is your optimal choice for high-efficiency, safe, and reliable drive solutions in hazardous environments. With up to 91.4% efficiency and optimized power factor, it greatly reduces energy consumption and operating costs. Certified to Exdb IIBT4 Gb explosion-proof standards, it ensures safe operation in explosive gas atmospheres.

Adopting F-class insulation, IP55 protection, and durable 6309/C3 bearings, the motor features strong stability, long service life, and S1 continuous duty for 24/7 operation. It is widely applied in petrochemical, coal mining, chemical, oil & gas, and green energy projects.

Backed by professional manufacturing and strict quality control, YBX3 motors deliver superior performance, safety, and cost-effectiveness for industrial users.

Production Details

Frame

• Compact and robust iron casting frame

• Universal IEC  installation dimensions available

• Customizable outlook and dimensions

---

Stator

• 99.9% pure copper winding for stator to ensure the output power and efficiency

• Excellent insulation system with 5 more processing flows

• All the windings are fitted in by handwork to ensure all slots are full and avoid any winding flaw.

---

Rotor

• Aluminum casting rotor with high quality silicon steel rotor core to assure induction efficiency

• Well and precisely machined shafts with good capacity of strength and toughness

---

Testing

• All motors must pass the piece testing before painting and packaging

• Type tests will be regularly performed for each series, more often for new developed series and variants.

---

Package and delivery

• All motors will be packaged well before delivery

• Plastic cover inside, vacuum tin foil outer and then solid wood box

---



Applications

YBX3 Explosion Proof Motor can be applied in areas with mixed dangerous and explosive gases, such as petroleum, chemical engineering, metallurgical industry, power and natural gas areas.

Chemistry

Coal mining

Metallurgy

Oil gas
