Z560-4A (U) Bulk Dc Motors 400 V 800kW

AIMIN ELECTRICS CO., LTD. is one of the leading manufacturers and suppliers of z560-4a (u) bulk dc motors 400 v 800kw in China. With abundant experience, we are committed to providing high quality customized products with competitive price. We warmly welcome you to buy bulk premium products made in China here and get quotation from our factory.

Brief Introduction

Manufactured by Xi'an AIMIN Motor Co., Ltd. (a leading bulk dc motors producer), the Z560-4A (U) is a high-performance direct current (DC) motor engineered for heavy-duty industrial applications. Certified to JB/T9577 standards and marked with the CE logo, it delivers a robust 800 kW output-ideal for scenarios requiring high power, such as large-scale conveyors, industrial pumps, or heavy machinery drives.

Operating at a 400 V main voltage (with a separate 180 V excitation supply), this motor draws a rated cur rent of 2148 A (excitation current: 33 A) and offers dual-speed flexibility: 450 r/min or 1350 r/min, adapting to variable load demands. Its IC 06 cooling system ensures stable thermal performance under continuous S1 duty (uninterrupted operation), supported by a Class 155 insulation system for durability in ambient temperatures of 0–40°C (at altitudes up to 1000 m).

Designed with reliability in mind, it features a IP23 protection rating (safeguarding against solid debris and light water spray) and heavy-duty bearings: NU240ECM (drive end) and 6238/C3 (non-drive end), built to withstand prolonged mechanical stress. Weighing 7470 kg, the motor balances rugged construction with functional design, making it suitable for industrial environments requiring consistent, high-power performance.

The Z560-4A (U) combines AIMIN's engineering expertise with compliance to international standards, serving as a dependable core component for high-load industrial systems among bulk dc motors .

Main Technical Parameters

Production Details

Frame

• Compact and robust iron casting frame

• Universal IEC installation dimensions available

• Customizable outlook and dimensions

---

Armature

• 99.9% pure copper bar for armature to ensure the output power and efficiency

• Excellent insulation system with 5 more processing flows

• All the copper bars are fitted in by handwork to ensure all slots are full and avoid any possible flaw.

---

Winding:

• All windings are made of pure copper to assure induction efficiency

---

Testing

• All motors must pass the piece testing before painting and packaging

• Type tests will be regularly performed for each series, more often for new developed series and variants.

---

Package and delivery

• All motors will be packaged well before delivery

• Plastic cover inside, vacuum tin foil outer and then solid wood box

---



Applications

Cement

Oil gas

Steel

Sugar

CHOOSE AIMIN, CHOOSE QUALITY!
