YE5-355M2-10 Three-phase Asynchronous V6 Mounting Motor 132kw 380V

AIMIN ELECTRICS CO., LTD. is one of the leading manufacturers and suppliers of YE5-355M2-10 Three-phase Asynchronous V6 Mounting Motor 132kw 380V in China. With abundant experience, we are committed to providing high quality customized products with competitive price. We warmly welcome you to buy bulk premium products made in China here and get quotation from our factory.

Brief Introduction

The YE5-355M2-10 is a high-efficiency, medium-sized three-phase asynchronous motor manufactured by Xi'an AIMIN Motor Co., Ltd., one of China's established industrial motor producers. Designed for heavy-duty, continuous-operation applications, this model delivers a rated output of 132 kW at 380 V / 50 Hz, making it suitable for driving pumps, fans, compressors, conveyors, crushers, mills, and other industrial machinery found in manufacturing plants, water-treatment facilities, mining operations, and photovoltaic power-generation auxiliary systems.

Performance and Efficiency

The motor is a 10-pole design with a synchronous speed of 600 r/min, running at a rated speed of approximately 590 r/min. It draws a rated current of 270 A and operates with a power factor (cos φ) of 0.78, connected in delta (Δ) winding configuration. Its rated efficiency reaches 95.2%, placing it in the highest efficiency tier of the YE5 series - equivalent to the ultra-premium efficiency class. This high efficiency translates directly into reduced energy consumption, lower operating costs, and a smaller carbon footprint over the motor's service life. The motor is rated for continuous duty (S1), meaning it can run at full load indefinitely without overheating.

Protection, Insulation, and Cooling

The enclosure is rated IP55, providing complete protection against dust ingress and water jets from any direction - well-suited for harsh industrial and outdoor environments. The insulation system is Class 155 (Class F), allowing the windings to withstand continuous operation at elevated temperatures while retaining a thermal margin for reliability and long service life. Cooling is achieved through IC411 (totally enclosed, fan-cooled by an integral shaft-mounted fan), which is simple, maintenance-friendly, and effective for most ambient conditions.

Mechanical Design

The motor uses LYC bearings: a cylindrical roller bearing (NU322) on the drive-end side for radial load support, and an angular contact ball bearing (7322) on the non-drive-end side to accommodate axial positioning. This bearing arrangement is engineered for high radial loads and balanced mechanical stability. The standard mounting configuration is IM V6 mounting motor, shaft pointing upward), though the series can be adapted to other mounting orientations depending on installation requirements. The unit weighs approximately 1560 kg, reflecting its robust cast-steel or fabricated-steel frame construction for vibration damping and structural rigidity.

Standards and Certification

The motor is built in accordance with enterprise standard Q/XD 510.292 and carries the CE mark, confirming compliance with applicable European health, safety, and environmental protection directives. A QR code on the nameplate allows traceability to production records and serial data.

Summary

The YE5-355M2-10 V6 mounting motor combines ultra-high efficiency, robust construction, IP55 protection, and Class F insulation in a 132 kW, 10-pole package. It is a dependable, energy-saving drive solution for demanding continuous-duty industrial applications, backed by AIMIN's manufacturing expertise and CE certification.

Main Technical Parameters

Production Details

Frame

• Compact and robust iron casting frame

• Universal IEC installation dimensions available

• Customizable outlook and dimensions

---

Stator

• 99.9% pure copper winding for stator to ensure the output power and efficiency

• Excellent insulation system with 5 more processing flows

• All the windings are fitted in by handwork to ensure all slots are full and avoid any winding flaw.

---

Rotor

• Aluminum casting rotor with high quality silicon steel rotor core to assure induction efficiency

• Well and precisely machined shafts with good capacity of strength and toughness

---

Testing

• All motors must pass the piece testing before painting and packaging

• Type tests will be regularly performed for each series, more often for new developed series and variants.

---

Package and delivery

• All motors will be packaged well before delivery

• Plastic cover inside, vacuum tin foil outer and then solid wood box

---



Applications

This series of motor is commonly used to drive water pumps, fans, compressors, conveyors and other transmission machinery in energy conservation and environmental protection transformation projects, national water conservancy projects, etc.

Power 2

Pump

Sugar

Water conservation
