YE4-315L2-6 Three-phase Asynchronous Motor 132kw 690V

AIMIN ELECTRICS CO., LTD. is one of the leading manufacturers and suppliers of ye4-315l2-6 three-phase asynchronous motor 132kw 690v in China. With abundant experience, we are committed to providing high quality customized products with competitive price. We warmly welcome you to buy bulk premium products made in China here and get quotation from our factory.

Brief Introduction

The YE4-315L2-6 three-phase asynchronous motor 132kw is a high-performance, super-premium efficiency solution engineered by Xi'an AIMIN Motor Co., Ltd., designed to meet the rigorous demands of modern industrial applications. Built on AIMIN's decades of expertise in motor manufacturing, this 132kW motor sets a new benchmark for energy efficiency, reliability, and operational cost savings, making it ideal for continuous-duty industrial environments.

At the core of its performance is the IE4-equivalent ultra-high efficiency rating, with an efficiency of 96.0% and a power factor (cosφ) of 0.86. This places it among the highest efficiency tiers globally, delivering substantial reductions in energy consumption compared to standard motors. For industrial facilities operating motors for extended hours-such as pumps, compressors, conveyors, and processing equipment-this translates to significant long-term cost savings and alignment with sustainability goals, reducing both operational expenses and carbon footprints.

Key specifications are tailored for robust performance: rated voltage of 690V, current of 134A, speed of 990r/min, and 50Hz frequency. The S1 continuous duty rating ensures stable operation under full load indefinitely, while the Class F thermal insulation system (155°C temperature class) enhances thermal stability and extends service life, even in high-temperature environments. Mechanical reliability is further reinforced by FAG 6319/C3 bearings on both the drive end (D.E.) and non-drive end (N.D.E.), which are designed for heavy loads and reduced vibration, minimizing maintenance needs.

Designed for durability in challenging industrial conditions, the motor 132kw features an IP55 protection grade, offering complete protection against dust ingress and resistance to low-pressure water jets. This makes it suitable for both indoor and outdoor installations, including humid or dusty environments. The IC411 cooling system (Totally Enclosed Fan-Cooled, TEFC) ensures consistent thermal management, preventing overheating and maintaining optimal performance across varying load conditions. Mounted in an IM B3 foot-mounted configuration, it is compatible with standard industrial machinery setups, enabling easy integration into new or existing systems.

Compliance with international standards underscores its quality: it bears the CE mark, meets GB/T 113299 standards, and is manufactured with precision engineering to ensure consistent performance. The motor's total weight of 1055kg reflects its robust construction, built to withstand the rigors of heavy industrial use.

In summary, the YE4-315L2-6 motor 132kw combines cutting-edge efficiency technology, robust mechanical design, and AIMIN's renowned manufacturing quality. It is the ideal choice for industrial operations seeking to optimize energy use, reduce maintenance costs, and enhance long-term operational reliability, backed by AIMIN's global support and service network.

Main Technical Parameters

Production Details

Frame

• Compact and robust iron casting frame

• Universal IEC installation dimensions available

• Customizable outlook and dimensions

---

Stator

• 99.9% pure copper winding for stator to ensure the output power and efficiency

• Excellent insulation system with 5 more processing flows

• All the windings are fitted in by handwork to ensure all slots are full and avoid any winding flaw.

---

Rotor

• Aluminum casting rotor with high quality silicon steel rotor core to assure induction efficiency

• Well and precisely machined shafts with good capacity of strength and toughness

---

Testing

• All motors must pass the piece testing before painting and packaging

• Type tests will be regularly performed for each series, more often for new developed series and variants.

---

Package and delivery

• All motors will be packaged well before delivery

• Plastic cover inside, vacuum tin foil outer and then solid wood box

---



Applications

This series of motor is commonly used to drive water pumps, fans, compressors, conveyors and other transmission machinery in energy conservation and environmental protection transformation projects, national water conservancy projects, etc.

Power 2

Pump

Sugar

Water conservation
