YRKK 630-6GR Three-phase Asynchronous High Voltage Power Supply 10kv 1600kw

AIMIN ELECTRICS CO., LTD. is one of the leading manufacturers and suppliers of yrkk 630-6gr three-phase asynchronous high voltage power supply 10kv 1600kw in China. With abundant experience, we are committed to providing high quality customized products with competitive price. We warmly welcome you to buy bulk premium products made in China here and get quotation from our factory.

Brief Introduction

The YRKK series high-voltage wound rotor three-phase asynchronous motor from AIMIN stands as your trusted heavy-duty power solution powered by high voltage power supply 10kv. Specially engineered for tough industrial operating conditions, this motor series excels in applications requiring high starting torque, widely deployed in metallurgy, mining, petrochemical, cement and hydropower sectors. The YRKK630-6GT model shown delivers a rated power of 1600kW with 6 poles and rated speed of 995r/min. Built with air-water cooling construction, IP54 protection grade and Class 155 insulation, it adopts S1 continuous duty to guarantee non-stop, stable long-term operation for your core production equipment.

Unlike conventional squirrel cage motors, the YRKK wound rotor design allows external starting resistors to be connected into the rotor circuit at startup. This smart structure effectively suppresses inrush starting current and minimizes grid impact, a critical advantage especially when running under high voltage power supply 10kv. The drive end uses NU238ECM bearing while the non-drive end adopts 6336/C3 bearing. Equipped with optimized compound sliding bearing lubrication system, it maintains stable lubrication under heavy shock loads. Both stator and rotor utilize Class 155 heat-resistant insulation materials, greatly improving overload resistance and extending the service life of the whole machine. Its air-water cooling system requires circulating cooling water before commissioning, keeping internal temperature steady even under sustained full-load operation.

Our motors are manufactured with strict quality standards and clear operation guidelines. Direct short-circuit startup of rotor windings is prohibited. External starting variable resistance must be fitted to the rotor loop before startup. Winding operation with earthing faults is not allowed. During installation, precise alignment of axial centerlines is required when coupled with driven machinery, to avoid excessive vibration and shaft damage. Adaptable to ambient temperatures ranging from -15℃ to 40℃ and altitude up to 2100 meters, it performs reliably in harsh, complex field environments across global projects.

Boasting rigid mechanical structure and low-vibration performance, the YRKK series drastically cuts your equipment downtime and maintenance expenditure. It serves as the preferred drive unit for ball mills, large fans, crushers and heavy-duty water pumps. When matched with high voltage power supply 10kv, this motor can continuously output massive power while effectively reducing grid interference during startup. Every unit passes comprehensive factory tests and holds CE certification. We support customized parameter adjustment according to your unique project demands, delivering durable, cost-effective heavy-load driving power for industrial clients worldwide.

Main Technical Parameters

Production Details

Frame

• Box structure frame, easy for maintaining and installation

• Flexible for special installation dimensions

• Customizable outlook and dimensions

---

Stator

• 99.9% pure copper winding for stator to ensure the output power and efficiency

• Excellent insulation system with 5 more processing flows

• All the windings are fitted in by handwork to ensure all slots are full and avoid any possible winding flaw.

---

Rotor

• Aluminum casting rotor with high quality silicon steel rotor core to assure induction efficiency

• Copper bar rotor is available for YKK motor

• Well and precisely machined shafts with good capacity of strength and toughness

---

Testing

• All motors must pass the piece testing before painting and packaging

• Type tests will be regularly performed for each series, more often for new developed series and variants.

---

Package and delivery

• All motors will be packaged well before delivery

• Plastic cover inside, vacuum tin foil outer and then solid wood box

---



Applications

Cement

Power Station

Water

Mining

CHOOSE AIMIN, CHOOSE QUALITY!
