DC Wound Motor

AIMIN ELECTRICS CO., LTD. is one of the leading manufacturers and suppliers of dc wound motor in China. With abundant experience, we are committed to providing high quality customized products with competitive price. We warmly welcome you to buy bulk premium products made in China here and get quotation from our factory.

Brief Introduction

DC wound motor that relies on DC operating voltage to operate. They are widely used in radio recorders, video recorders, DVD players, electric razors, hair dryers, electronic watches, toys, etc.

3．Brushless emergency DC motor  uses semiconductor switching devices to realize electronic commutation, that is, electronic switching devices are used instead of traditional contact commutators and brushes.It has the advantages of high reliability, no commutation sparks, low mechanical noise, etc., and is widely used in high-end recording stations, video recorders, electronic instruments and automated office equipment. The brushless DC motor is composed of a permanent magnet rotor, a multi-pole winding stator, a position sensor, etc.,

Position sensing commutes the current of the stator winding in a certain order according to the change in the position of the rotor (that is, it detects the position of the magnetic pole of the rotor relative to the stator winding, and generates a position sensing signal at the determined position, which is processed by the signal conversion circuit to control the power switching circuit, and the winding current is switched according to a certain logical relationship).The operating voltage of the stator winding is provided by an electronic switching circuit controlled by the output of the position sensor. There are three types of position sensors: magnetic, photoelectric and electromagnetic. Brushless DC wound motor using magnetically sensitive position sensors, and their magnetically sensitive sensor devices (such as hall elements, magneto-sensitive diodes, magneto-sensitive diodes, magneto-sensitive resistors, or application specific integrated circuits, etc.) are mounted on the stator assembly to detect changes in the magnetic field generated when the permanent magnet and rotor rotate.

A brushless emergency DC motor using a photoelectric position sensor is equipped with a photoelectric sensor device at a certain position on the stator assembly, the rotor is equipped with a shading plate, and the light source is a light-emitting diode or a small bulb.When the rotor rotates, due to the action of the shading plate, the photosensitive components on the stator will generate pulse signals intermittently at a certain frequency. Brushless DC motors that use electromagnetic position sensors have electromagnetic sensor components (such as coupling transformers, proximity switches, LC resonance circuits, etc.) installed on the stator assembly. When the position of the rotor of the permanent magnet changes, the electromagnetic effect will cause the electromagnetic sensor to generate a high-frequency modulated signal (its amplitude varies with the position of the rotor).

Main Technical Parameters

Production Details

Frame

• Compact and robust iron casting frame

• Universal IEC and NEMA installation dimensions available

• Customizable outlook and dimensions

---

Armature

• 99.9% pure copper bar for armature to ensure the output power and efficiency

• Excellent insulation system with 5 more processing flows

• All the copper bars are fitted in by handwork to ensure all slots are full and avoid any possible flaw.

---

Winding:

• All windings are made of pure copper to assure induction efficiency

---

Testing

• All motors must pass the piece testing before painting and packaging

• Type tests will be regularly performed for each series, more often for new developed series and variants.

---

Package and delivery

• All motors will be packaged well before delivery

• Plastic cover inside, vacuum tin foil outer and then solid wood box

---



Applications

Cement

Power Station

Pump

Sugar

CHOOSE AIMIN, CHOOSE QUALITY!
