ZDH09-40 T1 F2 40 Kw DC Motor 220V 1500rpm

AIMIN ELECTRICS CO., LTD. is one of the leading manufacturers and suppliers of zdh09-40 t1 f2 40 kw dc motor 220v 1500rpm in China. With abundant experience, we are committed to providing high quality customized products with competitive price. We warmly welcome you to buy bulk premium products made in China here and get quotation from our factory.

Brief Introduction

The 40 kw dc motor series from Xi'an AIMIN Motor Co., Ltd. represents a robust and reliable solution for industrial applications demanding high torque, precise speed control, and continuous operation under challenging conditions. Engineered with precision and built to last, this direct current motor is designed for heavy-duty environments where performance and durability are non-negotiable. The model ZDH09-40 T1 F2, prominently featured in the product lineup, delivers a rated power output of 40 kW at 220V DC, making it ideal for driving large machinery in sectors such as mining, steel processing, paper manufacturing, and heavy transportation systems.

One of the standout features of this 40 kw dc motor is its shunt excitation configuration, which ensures stable speed regulation across varying loads - a critical advantage in applications where consistent rotational velocity is paramount. With a rated speed of 1500 RPM and a thermal class of F (capable of withstanding ambient temperatures up to 40°C), the motor maintains efficiency and longevity even in thermally demanding settings. Its IP55 ingress protection rating safeguards internal components against dust and water jets, while the S1 duty cycle designation confirms its suitability for uninterrupted, continuous operation without overheating or degradation. Weighing 1215 kg, the motor's substantial mass reflects its rugged construction, engineered to absorb vibration and resist mechanical stress over extended service life.

The motor adheres to the enterprise standard Q/XD.514.017 and is manufactured under strict quality controls at Xi'an AIMIN's facilities, ensuring compliance with international safety and performance benchmarks. Its bearing configuration - 6314-2RZ/C3 on the drive end and 6313-2RZ/C3 on the non-drive end - is selected for high radial load capacity and extended lubrication intervals, reducing maintenance frequency. The inclusion of a QR code on the nameplate allows for quick access to digital documentation, serial tracking, and technical support, enhancing user experience and serviceability. Additionally, the motor's design accommodates altitude operation up to 1000 meters above sea level, broadening its applicability across diverse geographical regions.

Beyond its technical specifications, the 40 kw dc motor embodies AIMIN's commitment to industrial innovation and customer-centric engineering. Whether powering conveyor belts in bulk material handling, driving rolling mills in metal fabrication, or serving as prime movers in marine propulsion systems, this motor delivers unmatched reliability. Its compatibility with traditional DC drive systems makes it a seamless upgrade path for legacy installations seeking improved efficiency without full system overhaul. For engineers and procurement specialists evaluating long-term operational costs, the motor's energy-efficient design and low failure rate translate into significant savings over its lifecycle. As industries continue to demand higher productivity with lower downtime, the ZDH09-40 T1 F2 stands as a testament to enduring mechanical excellence - a true workhorse built for the rigors of modern industry.

Main Technical Parameters

Production Details

Frame

• Compact and robust iron casting frame

• Universal IEC installation dimensions available

• Customizable outlook and dimensions

---

Armature

• 99.9% pure copper bar for armature to ensure the output power and efficiency

• Excellent insulation system with 5 more processing flows

• All the copper bars are fitted in by handwork to ensure all slots are full and avoid any possible flaw.

---

Winding

• All windings are made of pure copper to assure induction efficiency

---

Testing

• All motors must pass the piece testing before painting and packaging

• Type tests will be regularly performed for each series, more often for new developed series and variants.

---

Package and delivery

• All motors will be packaged well before delivery

• Plastic cover inside, vacuum tin foil outer and then solid wood box

---



Applications

The motor can be widely used in many famous cement or concrete plants and many other similar industries.

Cement

Oil gas

Steel

Sugar

CHOOSE AIMIN, CHOOSE QUALITY!
