ZDL4-200-31T1 WF2 Shunt-excited 30kw Dc Motor 220 V

AIMIN ELECTRICS CO., LTD. is one of the leading manufacturers and suppliers of zdl4-200-31t1 wf2 shunt-excited 30kw dc motor 220 v in China. With abundant experience, we are committed to providing high quality customized products with competitive price. We warmly welcome you to buy bulk premium products made in China here and get quotation from our factory.

Brief Introduction

The ZDL4 series shunt-excited 30kw dc motor is a high-performance industrial drive product independently developed and manufactured by Xi'an AIMIN Motor Co., Ltd., a top domestic motor manufacturer with CE certification. Derived from the mature Z4 DC motor platform, this upgraded ZDL4 model inherits stable reliable performance, while optimizes structural design, insulation system and environmental adaptability. The representative ZDL4-200-31T1WF2 model delivers rated output power of 30kW, rated armature voltage of 220V, rated armature current of 151A, and constant rated speed of 1500r/min, fully meeting the precise speed regulation and high-torque driving demands of various industrial occasions.

Adopting independent shunt excitation (SHUNT) mode, this 30kw dc motor comes with a rated excitation current of 1.3A, achieving excellent speed stability, smooth speed regulation performance and strong overload capacity. It complies with national standard JB/T7592, equipped with Class 155 thermal insulation grade, IC411 self-ventilation cooling system and IP55 protection grade, which effectively prevents dust intrusion and splashing water damage, ensuring safe operation under harsh industrial environments. It supports standard V1 vertical mounting structure, configured with high-precision rolling bearings (DE:6314-2RZ/C3, NDE:6214-2RZ/C3), featuring low vibration, low noise and long service life. The whole motor weighs 525kg, adapts to ambient temperature from 0℃ to 40℃ and altitude below 1000m, with continuous S1 duty operation mode.

Certified by CE and produced under strict factory quality control, AIMIN ZDL4 series 30kw dc motor has outstanding dynamic performance and reliable operation stability. They are widely applied in machinery manufacturing, metallurgy, mining, paper making, packaging equipment, conveyor systems and other industries that require accurate speed adjustment and constant torque output. As a time-honored professional motor brand in China, AIMIN provides complete after-sales technical support and factory direct supply services, making ZDL4 series the ideal high-quality alternative for imported DC motors in global industrial driving fields.

Main Technical Parameters

Production Details

Frame

• Compact and robust iron casting frame

• Universal IEC  installation dimensions available

• Customizable outlook and dimensions

---

Armature

• 99.9% pure copper bar for armature to ensure the output power and efficiency

• Excellent insulation system with 5 more processing flows

• All the copper bars are fitted in by handwork to ensure all slots are full and avoid any possible flaw.

---

Winding

• All windings are made of pure copper to assure induction efficiency

---

Testing

• All motors must pass the piece testing before painting and packaging

• Type tests will be regularly performed for each series, more often for new developed series and variants.

---

Package and delivery

• All motors will be packaged well before delivery

• Plastic cover inside, vacuum tin foil outer and then solid wood box

---



Applications

Cement

Oil gas

Steel

Sugar

CHOOSE AIMIN, CHOOSE QUALITY!
