YKK5003-4w Three-phase Asynchronous 1000kw Motor Efficiency Class IE3

AIMIN ELECTRICS CO., LTD. is one of the leading manufacturers and suppliers of YKK5003-4w Three-phase Asynchronous 1000kw Motor Efficiency Class IE3 in China. With abundant experience, we are committed to providing high quality customized products with competitive price. We warmly welcome you to buy bulk premium products made in China here and get quotation from our factory.

Brief Introduction

Efficiency class IE3 is the core energy-saving feature of AIMIN YKK series high voltage three-phase asynchronous motors, which meets the international premium efficiency standard and delivers outstanding energy performance for heavy-duty industrial applications. Manufactured by Xi'an AIMIN Motor Co., Ltd., this YKK5003-4W model shown on the nameplate is a closed squirrel-cage motor equipped with air-to-water cooling system, IP54 protection grade and IC611 cooling method. Designed for S1 continuous duty operation, the motor adopts Class 155 insulation system to guarantee stable and safe long-time running. Its rated power reaches 1000kW, rated voltage 6300V, rated speed 1485 r/min and power factor 0.87, perfectly matching the demand of large-scale industrial equipment such as fans, water pumps, compressors and mills.

The motor adopts box-type welded frame structure, featuring high rigidity, low vibration and low noise. The bearing configuration can be customized according to operating conditions. This YKK5003-4W uses NU230ECM drive-end bearing and 6228/C3 non-drive-end bearing to support steady rotation under heavy load. The axial centering requirement must be strictly followed when connecting with driven machinery via coupling. The air-water cooling structure effectively controls temperature rise even under continuous full-load operation. The motor can adapt to ambient temperature from -15℃ to 40℃ and altitude up to 1000 meters, suitable for power, metallurgy, chemical and cement industries. Efficiency class IE3 ensures power loss reduction during long-hour operation, helping enterprises cut electricity cost and achieve green production targets.

Operational precautions should be followed before commissioning. For 2-pole units, rotation direction must align with the indicator mark. For air-water cooling squirrel cage motors, circulating cooling water must be filled as per nameplate data before startup. When adopting reduced-voltage starting under heavy load, users need to notice that starting torque drops with the square of starting voltage; extended starting time may lead to winding overheating and damage. For motors with compound grease lubricated sliding bearings, sufficient external circulating grease supply shall be confirmed prior to startup. Winding operation without proper earthing is prohibited.

Efficiency class IE3 makes this YKK series stand out among high-voltage industrial motors. With CE certification and compliance with JB/T12730 standard, AIMIN YKK high voltage asynchronous motors are rigorously tested before delivery. The 1000kW unit weighs 5040kg, with stable performance and easy maintenance. The whole series covers multiple power and speed specifications, offering reliable high-efficiency drive solutions for heavy industrial sites. It balances high output capacity, mechanical strength and energy conservation, becoming a preferred selection for large fixed industrial equipment.

Main Technical Parameters

Production Details

Frame

• Box structure frame, easy for maintaining and installation

• Flexible dimensions

• Customizable outlook

---

Stator

• 99.9% pure copper winding ensures the output power and efficiency

• Excellent insulation system with 5 more processing flows

• All the windings are fitted in by handwork to ensure all slots are full and avoid any possible winding flaw.

---

Rotor

• Aluminum casting rotor with high quality silicon steel rotor core to assure induction efficiency

• Copper bar rotor is available for YKK motor

• Pprecisely machined shafts with good capacity of  toughness

---

Testing

• All motors must pass the testing before painting and packaging

• We regularly test existing and new products to ensure quality.

---

Package and delivery

• All motors will be packaged well before delivery

• Plastic cover inside, vacuum tin foil outer and then solid wood box

---



Applications

YKK  Motor is the widely used in many general industries, such as blowers, pumps, crushers, cutting machines, and many other heavy machines. For more application details, contact us.

Cement

Power Station

Water conservation

Steel
