YRKK800-10 3kv Motor

AIMIN ELECTRICS CO., LTD. is one of the leading manufacturers and suppliers of yrkk800-10 3kv motor in China. With abundant experience, we are committed to providing high quality customized products with competitive price. We warmly welcome you to buy bulk premium products made in China here and get quotation from our factory.

Title:

YRKK Medium & High Voltage Slip Ring Three Phase Motor

Brief Introduction

The main proper of YRKK series 3kv motor stator winding adopts 155 (F) class insulation material and conducts VPI treatment, therefore, this type of motor has characteristics of good insulation performance, high mechanical strength, strong anti-moisture capacity as well as long service life.

For extra-large 3kv motor, the stator core punch may need to be spliced through several fan-shaped blades, which is an inevitable factor that causes the motor to have shaft current; however, if the number of splices can be reasonably controlled, the risk of shaft current generation will be greatly reduced.Professional research has found that after the ratio of the number of splicing joints of the iron core to the logarithm of the motor pole is approximately the simplest fraction, if the molecule is odd, there will be axial current, and if the molecule is even, there will be no axial current.For this rule, on the one hand, it may be deduced and demonstrated through professional theory, and on the other hand, it may also be verified by practice.

When there is a shaft voltage in the 3kv motor, for a motor with a rolling bearing structure, as long as the shaft voltage does not exceed 350 millivolts, in principle, it will not pose a threat to the bearing, otherwise the necessary avoidance measures should be taken.When the shaft voltage is high, circuit breaking or bypass measures can be taken according to the actual structure of the motor or specific operating conditions.

For 3kv motor with shaft voltage, shaft current will affect the bearing system to varying degrees, but how much current will directly affect the bearing is always a matter of concern to everyone.The measurement of shaft current is relatively difficult, but it can be basically detected by some high-end measuring devices; empirical statistics show that when the shaft current does not exceed 1 amp, it will basically not affect the quality of bearing operation; when the shaft current exceeds 1 amp but does not reach 1.5 amp, the bearing system will be significantly abnormal after hundreds of hours of motor operation; when the shaft current exceeds 2 amp, it may only be a few hours, and the bearing system will be severely corroded by electricity consequences.

Main Technical Parameters

Why choose AIMIN Brand YRKK series of Motor?

YRKK series motors are extremely durable and can operate stably in high-load and long-term working environments.It uses high-strength materials and precision manufacturing technology, simemotor.com ensures the reliability of the motor in harsh environments.

Production Details

Frame

• Box structure frame, easy for maintaining and installation

• Flexible for special installation dimensions

• Customizable outlook and dimensions

---

Stator

• 99.9% pure copper winding for stator to ensure the output power and efficiency

• Excellent insulation system with 5 more processing flows

• All the windings are fitted in by handwork to ensure all slots are full and avoid any possible winding flaw.

---

Rotor

• Aluminum casting rotor with high quality silicon steel rotor core to assure induction efficiency

• Copper bar rotor is available for YKK motor

• Well and precisely machined shafts with good capacity of strength and toughness

---

Testing

• All motors must pass the piece testing before painting and packaging

• Type tests will be regularly performed for each series, more often for new developed series and variants.

---

Package and delivery

• All motors will be packaged well before delivery

• Plastic cover inside, vacuum tin foil outer and then solid wood box

---



Applications

Cement

Power Station

Water

Mining

CHOOSE AIMIN, CHOOSE QUALITY!
