ZDB-61KF1 DC Motor 220v 3000 Rpm 17kW

AIMIN ELECTRICS CO., LTD. is one of the leading manufacturers and suppliers of zdb-61kf1 dc motor 220v 3000 rpm 17kw in China. With abundant experience, we are committed to providing high quality customized products with competitive price. We warmly welcome you to buy bulk premium products made in China here and get quotation from our factory.

Brief Introduction

Product Overview

The ZDB-61K.F1 series is a high-performance industrial direct current shunt motor 220v 3000 rpm independently developed and manufactured by Xi'an AIMIN Motor Co., Ltd., a leading domestic motor manufacturer with authoritative CE certification. This model adopts mature and stable shunt excitation structure, and the standard rated specification is 17kW output power, 220V rated armature voltage, 88.9A rated armature current, and 2950rpm stable synchronous speed. Designed in strict accordance with national industrial standards STD.QXD.514.017, it supports continuous S1 duty operation, and fully adapts to conventional industrial operating environments with ambient temperature ranging from 0℃ to 40℃ and altitude below 1000m. With compact overall structure, reliable mechanical rigidity and optimized electromagnetic design, this DC motor inherits AIMIN's consistent stable manufacturing technology, realizing excellent speed regulation performance and steady output torque, and becoming a preferred power drive solution for precision industrial transmission equipment.

Core Technical Advantages

This ZDB-61K.F1 DC motor 220v 3000 rpm is equipped with top-tier configuration in all core components. Both drive end (D.E.) and non-drive end (N.D.E.) adopt imported SKF 6308/C3 high-precision bearings, which greatly reduce mechanical vibration, noise and wear, and significantly extend the motor service life. It applies IC01 self-ventilation cooling system, efficient heat dissipation performance matching Class F thermal insulation grade, which ensures stable operation under long-time full-load working conditions. The motor reaches IP23 protection grade, effectively preventing solid foreign matter intrusion while meeting industrial ventilation requirements. The shunt excitation (SHUNT) excitation mode provides outstanding speed regulation linearity and stable dynamic response, delivering constant torque output under variable speed conditions. With a total weight of 172kg optimized mechanical body, it achieves an excellent balance between power density, structural strength and operational reliability. Every production unit has unique serial number traceability, realizing full-life cycle quality management.

Paragraph 3: Application Scenarios & Brand Strength

As a certified high-quality DC motor 220v 3000 rpm product from AIMIN, the ZDB-61K.F1 series boasts wide industrial applicability and stable market performance. It is perfectly suitable for precision speed regulation driving scenarios including machine tools, conveyor equipment, printing machinery, packaging lines and other industrial automation fields that require stable torque and adjustable speed performance. Supported by Xi'an AIMIN Motor's complete quality control system and professional after-sales service team, this motor features high operational stability, low failure rate and convenient maintenance. With CE certification compliance, it meets international industrial safety standards and can be widely exported to global markets. Integrating reliable performance, premium configuration and cost-effective advantages, the ZDB-61K.F1 DC motor provides efficient, stable and long-life power support for global industrial manufacturing upgrading and intelligent transmission equipment.

Main Technical Parameters

Production Details

Frame

• Compact and robust iron casting frame

• Universal IEC installation dimensions available

• Customizable outlook and dimensions

---

Armature

• 99.9% pure copper bar for armature to ensure the output power and efficiency

• Excellent insulation system with 5 more processing flows

• All the copper bars are fitted in by handwork to ensure all slots are full and avoid any possible flaw.

---

Winding

• All windings are made of pure copper to assure induction efficiency

---

Testing

• All motors must pass the piece testing before painting and packaging

• Type tests will be regularly performed for each series, more often for new developed series and variants.

---

Package and delivery

• All motors will be packaged well before delivery

• Plastic cover inside, vacuum tin foil outer and then solid wood box

---



Applications

The motor can be widely used in many famous cement or concrete plants and many other similar industries.

Cement

Oil gas

Steel

Sugar

CHOOSE AIMIN, CHOOSE QUALITY!
