Z4-400-32 600 Rpm DC Motor 440kW 440V Seperate Exciting

AIMIN ELECTRICS CO., LTD. is one of the leading manufacturers and suppliers of z4-400-32 600 rpm dc motor 440kw 440v seperate exciting in China. With abundant experience, we are committed to providing high quality customized products with competitive price. We warmly welcome you to buy bulk premium products made in China here and get quotation from our factory.

Brief Introduction

Our AIMIN Z4 series 600 rpm dc motor represented by the model Z4-400-32 is a high-performance separately excited direct current motor professionally manufactured by Xi'an AIMIN Motor Co., Ltd., strictly produced in accordance with the national standard JB/T 6316 to deliver stable, adjustable-speed driving performance for heavy-duty industrial production lines. This 440kW 440V industrial motor is engineered to cope with frequent speed regulation, heavy startup load and continuous long-time operation under S1 working duty, making it a core driving component widely adopted in metallurgical rolling mills, mining conveyors, cement production equipment, paper making machinery and large hydraulic pump stations.

With a rated rotational speed of 600 revolutions per minute, this 600 rpm dc motor features a separately excited design with a 180V excitation voltage and rated excitation current of 29.0A, which enables precise independent control over motor torque and rotating speed. Operators can flexibly adjust the output speed within a wide range without sacrificing stable torque output, perfectly matching the variable working condition requirements of modern industrial automated production. The motor adopts IP21S protection grade and IC06 self-ventilated cooling structure, paired with Class 155 high-temperature resistant insulation material, effectively avoiding insulation aging caused by long-time continuous operation and frequent load fluctuations, greatly extending the service life of the whole motor.

In terms of structural configuration, this heavy-duty motor is designed with classic IM B3 horizontal foot mounting installation, which is convenient for on-site fixing, alignment and daily maintenance for most industrial equipment. Two heavy-duty C3 clearance rolling bearings are equipped on both drive end and non-drive end, adopting 6326/C3 for the drive side and 6226/C3 for the non-drive side. The large-size wide-gap bearings can withstand huge radial and axial impact loads generated during heavy-load startup and frequent forward-reverse rotation, effectively preventing bearing heating, vibration and abnormal wear under long-time high-load running. The whole motor weighs 4010kg, with a robust cast iron frame that greatly improves mechanical rigidity and anti-vibration capacity, ensuring stable operation even under harsh on-site working conditions.

For environmental adaptability, the AIMIN Z4 series 600 rpm dc motor can normally run within an ambient temperature range of 0℃ to 40℃ and an altitude below 1000 meters above sea level. The CE certification proves that this motor complies with European safety production standards, supporting stable export sales to global markets. Compared with conventional low-speed DC motors, our motor balances high torque output and operating efficiency, avoiding extra energy loss caused by speed reducer configuration for many low-speed driving scenarios, helping enterprises reduce overall equipment investment and long-term power consumption costs. Every finished motor undergoes strict factory tests on insulation resistance, no-load operation, load temperature rise and vibration detection before delivery, with unique production serial numbers to realize full lifecycle quality traceability, providing global industrial users with safe, durable and efficient DC driving solutions.

Main Technical Parameters

Production Details

Frame

• Compact and robust iron casting frame

• Universal IEC  installation dimensions available

• Customizable outlook and dimensions

---

Armature

• 99.9% pure copper bar for armature to ensure the output power and efficiency

• Excellent insulation system with 5 more processing flows

• All the copper bars are fitted in by handwork to ensure all slots are full and avoid any possible flaw.

---

Winding

• All windings are made of pure copper to assure induction efficiency

---

Testing

• All motors must pass the piece testing before painting and packaging

• Type tests will be regularly performed for each series, more often for new developed series and variants.

---

Package and delivery

• All motors will be packaged well before delivery

• Plastic cover inside, vacuum tin foil outer and then solid wood box

---



Applications

Cement

Oil gas

Steel

Sugar

CHOOSE AIMIN, CHOOSE QUALITY!
